EasyGates AK1 – Outdoor Easy Keypad

The AK1 is a freestanding Access Control system with an integrated keypad and card reader. For use with a single entrance.

Unfortunately, this product is temporarily out of stock. We are awaiting information regarding the availability of this product.

Contact Us

Please contact us for alternatives and assistance.

SKU: K1 Category: Tag:



Weather Resistant

Wide Temperature Range

Card / Pin Entry

The AK1 is a freestanding Access Control system with a single entrance with an integrated keypad and card reader.

Its weatherproof design makes it suitable for outdoor use.

AK1 Outdoor Keypad from the side

Standalone Keypad

The AK-1 outdoor keypad is a stand-alone keypad that can be linked to various access control systems. You can manage who has access to your property through a single NO/NC relay.

Expecting Guests

If you are expecting guests, you can provide up to 10 visitors with pin codes with or cards that are good for up to 10 uses.

AK1 Outdoor Keypad Visitor Pass
AK1 Outdoor Keypad Backlit Keys

No More Fumbling

Thanks to the integrated backlit keypad, the AK-1 is usable at any time of the day or night, without needing to fumble in the dark or install a secondary light source.

Weather & Vandal Proof

No need to worry about what the weather is up to with the AK-1. With its IP66 weatherproof protection rating, you can rest easy that come rain or shine your keypad will be fully functional and resistant to anything you can throw it's way!

AK1 Outdoor Keypad Weather Proof


  • Metal case, illuminated keypad
  • 1000 users (990 regular users + 10 visitor users)
  • 3 access modes: Card, PIN, Card + PIN
  • PIN length: 46 characters
  • Anti-tamper warning
  • IP66 weather resistance
  • Card type: 125KHz EM card/13.56MHz Mifare card

Manuals & Datasheets

AK1 Outdoor Easy Keypad Manual
AK1 Outdoor Easy Keypad Quick Setup Guide

Alternative Model Numbers

AK1, K1

Product Specifications

Physical and Performance Attributes

Weight500 grams
Dimensions (L x W x H)25 × 76 × 117 mm
Protection Rating (IP)66
Vandal Resistant?Yes
Mounting TypeSurface Mounted
Operating Temperature-40°C~ 60°C
Operating Humidity10%RH - 90%RH

Electronics Attributes

Voltage9~18V DC

Access Control Attributes

Number of Codes1000
Code Length4~6 digits
Number of Relays1
Relay OutputNO & NC
Backlit KeysYes
