Nice Robus 1000 + 4m Steel Rack

Motor Voltage:
24v
Max Weight:
1000KG
Max Length:
12M
  • Nice branded sliding gate opener kit
  • Very quiet and smooth operation
  • Strong and sturdy pressure die cast design
  • Connect accessories with just two wires via BlueBUS

£1,050.31

Accessories

Nice Robus 600 - 1000 Sliding Gate Kit With Steel Rack
This item: Nice Robus 1000 + 4m Steel Rack
£1,050.31
£1,050.31
Nice IT4WIFI Interface Side
£139.79
Nice BiDi WiFi Pocket Programming Interface
£40.36
Nice Era One ON2E Remote Control
£30.88
Nice Era EPMB BlueBUS Surface-Mounted Photocells
£60.48
Nice Era PPH3 Aluminium Photocell Post (500mm)
£67.85
Nice EDSWG Keypad
£124.67
Nice PS124 24v Backup Battery
£113.14

SKU: ROBUS1000-4M Category: Tag:

Description

Nice Robus 1000 24v sliding gate opener kit with electromechanical limit switch for sliding gates up to 1000kg and 12m, complete with 4m steel rack.

Very quiet and smooth operation thanks to the gear motor on bearings.

Features

Safe and Intelligent

  • Fully compatible with Nice’s Solemyo solar power kit and Opera management system for GPRS and Bluetooth connectivity / operation
  • Connection for EN compliant 8.2K safety edges
  • The Nice Robus series is equipped with a temperature sensor which adapts the motor power to the climatic conditions, enabling high performance whatever the weather
  • A master and slave selection can automatically synchronise two motors, this makes it possible to automate 2-leaf sliding gates set opposite each other
  • Features an obstacle detection system and automatic programming of opening times, and acceleration and deceleration can be adjusted at the beginning and end of each opening and closing manoeuvre
  • The Robus is capable of self-diagnosis, alerting the user to faults via flashing lights

Sturdy, Practical and User Friendly

  • The Nice BlueBUS system enables the user to power and control a maximum of seven sets of photocells using only two wires
  • The control unit and backup battery (optional) can be connected by means of a simple connector and can be housed directly inside the motor
  • The Robus’s gear motor is on bearings, resulting in very quiet and smooth operation
  • Strong and sturdy pressure die cast design
  • Aluminium release handle for easy opening

Downloadable Materials

What’s Included

  • 1 x RB1000 Motor with electromechanical limit switch (24v)
  • 1 x RBA3 Integrated control unit
  • 2 x ON2E Remotes
  • 1 x EPMB Pair of Bluebus Photocells
  • 1 x OXI Receiver
  • 4m Steel Rack

Product Specifications

Physical and Performance Attributes

Weight25 KG
Dimensions (L x W x H)210 × 330 × 303 mm
Dimensions

Motor Dimensions: 330 x 303 x 210 mm

Motor Weight: 13 kg

Protection Rating (IP)44
Operating Temperature-20°C to +50°C

Electronics Attributes

Max Absorption2.3 A
Max Power450 W
Power Supply230v AC (50/60 Hz)

Motor Attributes

Duty Cycle / Work Cycle

50 (Cycles / Hour)

Motor Voltage24v
Safety Edge Input8K2OHM, NC, NO
Automation TypeSliding
Kit TypeSingle
Max. Gate Leaf Length (M)12M
Max. Gate Weight (KG)1000KG
Motor Model Number(s)

RB1000

Pinion ModM4
Option for Slave MotorYes
