EZVIZ DB2 – Battery-powered Video Doorbell Kit (Grey / White)

EZVIZ’s Video Doorbell has a great 2K Resolution camera and Weatherproof casing for Outdoor use.

The EZVIZ DB2 – Battery-powered Video Doorbell Kit is available in Grey / White.


EZVIZ DB2 – Battery-powered Video Doorbell Kit (Grey / White) is compatible with the following systems:
Works with AlexaWorks with the Google Assistant



EZVIZ DB2 – Battery-powered Video Doorbell Kit
This item: EZVIZ DB2 - Battery-powered Video Doorbell Kit (Grey / White)

SKU: CS-DB2-A0-2C3WPB/G Categories: ,

EAN / Barcode: 6941545607511


EZVIZ Battery-powered Video Doorbell Kit

  • Battery powered video doorbell, easy to install
  • Boasting 2K Resolution, high quality picture.
  • Compatible with Amazon Alexa, Google Assistant and IFTTT
  • AI Human Detection
  • Answer your door via the EZVIZ app wherever you are
  • Secure the entry point of your home for peace of mind
  • Push notifications sent to your phone when motion is detected.
  • Superb 176-degree vertical head to toe viewing angle, 105-degrees horizontally – giving you the best picture.
  • 2 years’ warranty and 24/7 Tech Support

Introducing the EZVIZ DB2 Battery Video Doorbell with AI Human Detection

EZVIZ’s Video Doorbell has a great 2K Resolution camera and Weatherproof casing for Outdoor use. With a 5200mAh rechargeable battery in the DB2 means simple DIY installation, It’s 170-degree vertical viewing angle lets you see who’s there from head to toe and even talk to them when you are not home. Connect it to your smartphone via the EZVIZ app to keep your home safe.

Answer the door from anywhere – The Doorbell initiates a video call via the EZVIZ App when someone rings your doorbell, so you’ll never miss a visitor. See and talk to your visitors from your smartphone anywhere, any time. The built-in microphone and speaker make it easy for you to hear what’s happening outside the door.

Be Informed – With its AI algorithm on board, the DB2 intelligently detects a person’s movement, ensuring that you only receive notifications when people move by. You can turn off this function if you need other motion alerts such as those triggered by animals or cars. Motion detection alerts will trigger a notification to be sent to your smartphone via the EZVIZ app which brings attention to the event occurring from wherever you are.

Easy Installation – Because it is battery powered, there are no wires! Simply install where you want and connect to the EZVIZ app via app as you would any of our other cameras.

Chime unit – The DB2 chime rings at up to 65 decibels within a three-meter radius and it comes equipped with 20 pleasant ringtones to choose from. You never miss a ring call at home even without your phone! Simply plug-in and connect via the app.

Amazon Alexa & Google Home Compatible – Using the sound of your voice you can view live footage via your Amazon Alexa and Google Hub

Secure Your Home Day & Night – Infrared helps deliver crystal clear night vision, providing 24/7 security in your home or office.

Two-way Talk – The internal microphone supports audio pickup within five meters and video recording with sound, meaning you can have a two-way conversation if needed via the EZVIZ app.

Storage of footage – EZVIZ cameras can hold a MicroSD card (up to 256GB) for local storage upon each detection, or alternatively you can sign up to EZVIZ’s Cloud Storage system (subject to subscription costs)

What’s in the box

  • DB2 Video Doorbell (White / Grey)
  • Chime
  • Mounting Plates
  • Inclined Mounting Plates (2)
  • Screwdriver and Screw Kits (2)
  • Foam Sticker
  • Plate Foam
  • Drill Template
  • Pin
  • U-shaped Wire and Wire Connectors (3)
  • Power Cable
  • Quick Start Guide
  • Installation Guide
  • Regulatory Information

General Specifications

Operation Conditions: -20°C to 50°C (-4°F to 122°F),

Humidity: 95% or less (non-condensing)

Ingress Protection Grade: IP65

Weight: 241.35 g (8.5 oz)

Size: 150 x 58 x 32 mm (5.91 x 2.28 x 1.24 inch)

Battery Capacity: 5200mAh rechargeable lithium battery

Power Supply: DC5V±10% 2A

Power Consumption: Max. 2W

Intelligent Alarm: PIR + human shape smart motion detection

Tamper Alarm: Sound and light anti-dismantling alarm (supports sending alerts to the smartphone)

Video Intercom: Long-distance video two-way talk

Sensing Angle: 100°

Sending Distance: Max. 5 m (16.4 ft)

Sensitivity: User adjustable (High, Medium and Low Sensitivity)

Audio Input: Built-in high-sensitivity microphone

Audio Output: Built-in high-power speaker

Reset button: Yes

Network Specifications

Protocol: EZVIZ Cloud Proprietary Protocol

Interface Protocol: EZVIZ Cloud Proprietary Protocol

Wi-Fi Standard: IEEE802.11b, 802.11g, 802.11n

Frequency Range: 2.4 GHz ~ 2.4835 GHz

Channel Bandwidth: Supports 20 MHz

Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

Transmission Rate: 11b: 11Mbps, 11g :54Mbps, 11n :150Mbps

Audio / Video

Image Sensor: 1/2.7″ Progressive Scan CMOS (Supports low light sensitivity)

Lens: 2.0 mm @ F2.0, view angle: 176° (Diagonal)

Day & Night: IR-cut filter with auto-switching

Max. Resolution: 2000 x 1504


Video Compression: H.265 / H.264

Frame Rate Max: 15fps; Self-Adaptive during network transmission

Chime Specifications

Size: 100 x 55 x 35 mm (3.94 x 2.17 x 1.38 inch)

Power Supply: AC 110 ~ 240V

Wi-Fi Standard: IEEE802.11b, 802.11g, 802.11n

Ringtone: Supports 20 ringtones with adjustable volume levels

Audio Output: 72 dB within 1 meter

Storage Supports: microSD card up to 256 GB

Weight: 120 g (4.2 oz)

Product Specifications

Physical and Performance Attributes

Weight400 grams
Dimensions (L x W x H)28.3 × 19.2 × 9.1 mm
Protection Rating (IP)65
Mounting TypeSurface Mounted

Electronics Attributes

Max ConsumptionMax. 2W
Power SupplyDC5V±10% 2A / 5200mAh rechargeable lithium battery
