Chamberlain TPD10-05 Swing Gate 24V Opener Kit

Motor Voltage:
24v
Max Weight:
250KG
Max Length:
2.5M

The Chamberlain TPD10-05 is a simple yet sophisticated residential gate opener kit designed for domestic driveway gates. With fail safe photocells, 24V motors and a control panel with 8.2K Safety edge inputs, the kit is an ideal residential gate opener.

£322.80

Accessories

Chamberlain TPD10-05 Kit Contents
This item: Chamberlain TPD10-05 Swing Gate 24V Opener Kit
£322.80
£322.80
Chamberlain TX4RUNI 4-Channel Remote Control
£34.80
Chamberlain 771REV Photocells
£35.40
LiftMaster FLA-24
£32.76

SKU: TPD10-05 Category: Tag:

EAN / Barcode: 4014243213970

Gate Measurement Video Guide

If you need help determining the A / B measurements of your gate, check out our helpful video guide (right).

Description

The Chamberlain TPD10-05 is a simple yet sophisticated residential gate opener kit designed for domestic driveway gates. The 24v motors are suitable for gates up to 2.5m in length (at 150Kg), or 1.5m (at 250Kg).

With automatic position searching, the TPD10 is equipped with basic programming for limit searches & remote learning.

Please check imagine for geometry chart for suitability.

Features

  • Reliable, convenient and safe
  • Automatic closing function and power setting
  • Soft start / soft stop function
  • No harsh banging/clattering of the gates
  • Manual release is possible if there is no power
  • Pedestrian mode: option to open just one leaf
  • 8.2K Safety edge input

What’s Included

  • 2 x TPD10-05 Ram Type Gate Openers
  • 1 x Control Board & Enclosure
  • 1 x TX4RUNI 4 button remote control
  • 1 x Pair of 771REV Safety Photocells
  • 1 x Instruction manual
  • 4 x Mounting brackets
    • 2 x gate bracket, 2 x post bracket
  • 1 x Transformer & base plate
  • 1 x Radio receiver
  • Miscellaneous installation hardware

Manual

Chamberlain TPD10-05 Gate Opener Manual

Product Specifications

Physical and Performance Attributes

Weight13.5 KG
Dimensions (L x W x H)635 × 210 × 210 mm
Dimensions

Packaging:

Width: 21 cm
Length: 63.5 cm
Height: 21 cm

Protection Rating (IP)44
Operating Temperature-20°C to +55°C

Electronics Attributes

Max Power40W
Power Supply230VAC / 50-60 Hz
VoltageOutput to motor - 24VDC max.
Supply accessories - 24VDC - 100mA
Transformer230/24VAC minimum 60VA
Input Voltage230-240 V, 50 Hz

Motor Attributes

Duty Cycle / Work Cycle

Cycles/24H: 5-10
Duty Cycle: 4 minutes

Motor TypeElectromechanical
Motor Voltage24v
Safety Edge Input8K2OHM
Soft-Start / Soft-StopYes
Automation TypeRam
Kit TypeDouble
Max. Gate Leaf Length (M)2.5M
Max. Gate Weight (KG)250KG
Force (N)3000N
Number of Leafs2
Max Opening Angle105°
