AX-S AX230KR RFID Standalone Access Control Keypad

Secure Access Made Easy with the AX-S AX230KR Keypad. Support for up to 1010 users, weather-resistant design, and dual relay outputs. The ideal choice for outdoor access control. Find all the details in the included user manual and datasheet. Upgrade your security today!



AX-S AX230KR RFID Standalone Access Control Keypad
This item: AX-S AX230KR RFID Standalone Access Control Keypad
Prastel KT-10 - Proximity Tag
Meanwell HDR-15 Series DIN Rail PSU
Meanwell HDR-15 Series DIN Rail PSU

SKU: AX230KR Category:

EAN / Barcode: 5061030100011


The AX-S AX230KR keypad is a combined proximity and keypad access point, with capacity for 1010 users. This standalone, vandal-resistant wired keypad includes backlit keys for ease of use in the dark.

Ideal for outdoor use thanks to the weather-resistant IP65 protection rating.


  • Up to 1010 users (Relay 1 – 1000 Users, Relay 2 – 10 Users, or combined) (proximity cards / tokens and PINs)
  • 12 Digit Backlit keypad, 2-6 digit pin access
  • Die-cast zinc alloy, epoxy sealed
  • Built-in proxy reader with EM125Khz RF frequency – Effective Distance: 5cm
  • Weather resistant IP65 protection
  • Vandal resistant
  • 2 LED indicators with audible indication
  • Operating voltage 12~24VAC/DC
  • Dual Relay Outputs

What’s Included

  • Keypad
  • Allen Wrench
  • 4 x Plastic wall plugs
  • 4 x Screws
  • 1 x Locking Screw

Manuals & Datasheets

Product Specifications

Physical and Performance Attributes


21mm x 76mm x 119mm

Protection Rating (IP)65
Vandal Resistant?Yes
Mounting TypeSurface Mounted
Operating Temperature-30°C ~ 70°C

Electronics Attributes

Input Voltage12~24 VAC VDC

Remote Control, Radio & Receiver Attributes

Number of Relay Outputs2
Type of OutputsNO & NC
Number of Channels2
Number of Users

Relay 1: 1000 Users
Relay 2: 10 Users, or combined

Access Control Attributes

Number of Relays2
Relay OutputNO & NC
